16-60 Tray Vacuum Drying Oven for Pharmaceutical API Low-Temperature Drying

Designed for efficient and safe drying of pharmaceutical APIs and heat-sensitive fine chemicals, this vacuum drying oven offers a tray capacity of 16-60 pcs and an evaporation area of 5-18 m². Operating at a maximum temperature of 80°C, it minimizes thermal degradation of active ingredients, ensuring product quality and yield.

Key Features

• Low-temperature operation (≤80°C) – Protects heat-sensitive APIs from degradation, ensuring high product quality.
• Vacuum drying environment – Achieves ultimate vacuum of ≤10 Pa, enabling efficient moisture removal at low temperatures.
• Multi-tray design (16-60 trays) – Increases loading capacity and throughput, ideal for batch production.
• Material options SS304/SS316L – Corrosion-resistant and GMP-compliant, suitable for pharmaceutical applications.

Technical Specifications

Models and Options

Available in the ZDF-6 to ZDF-30 series with customizable tray counts and materials (SS304, SS316L, Titanium, Hastelloy) to suit specific process requirements.

Materials and Structure

Constructed from high-grade stainless steel (SS304/SS316L) for corrosion resistance and GMP compliance. The chamber is designed for simple single-batch processing, ideal for small-batch high-value API production.

Applications

Primarily used in the pharmaceutical industry for drying heat-sensitive APIs, as well as in fine chemical applications where low-temperature drying is essential to maintain product integrity.

Customization

We offer customizations including tray size, material grade, and control systems to meet your specific drying needs.

FAQ

Q: What is the maximum operating temperature?

A: The maximum temperature is 80°C, which is ideal for heat-sensitive materials.

Q: Can the oven handle flammable solvents?

A: Yes, models with explosion-proof ratings (Ex d IIB T4) are available for such applications.

Q: What are the available material options?

A: We offer SS304, SS316L, titanium, and Hastelloy to accommodate various chemical compatibilities.

Q: What is the minimum order quantity?

A: The MOQ is 1 unit, and we provide pre-shipment testing.

Q: How does vacuum drying protect APIs?

A: By reducing pressure, moisture evaporates at lower temperatures, minimizing thermal degradation.
