Corrosion-Resistant Vacuum Drying Oven with Hastelloy Chamber for Acidic Chemicals
This vacuum oven is designed to withstand the harshest chemical environments. With an enamel or Hastelloy-lined chamber, it resists acid and alkali corrosion, making it ideal for drying highly corrosive chemical products. The low-temperature drying capability protects sensitive compounds from degradation.
Key Features
- Hastelloy or enamel lining – Provides exceptional resistance to acid and alkali corrosion, extending equipment lifespan.
- Low-temperature drying (≤80°C) – Safe for heat-sensitive and chemically aggressive products.
- GMP-compliant design – Suitable for pharmaceutical applications requiring high purity and cleanliness.
- Materials: SS304, SS316L, Titanium, Hastelloy – Options to match specific chemical compatibility needs.
Technical Specifications
| Parameter | Range |
|---|
| Max. Temperature | 80°C |
| Steam Pressure | 0.2-0.6 MPa |
| Lining Materials | Enamel, Hastelloy |
| Number of Trays | 16-60 pcs |
Models and Options
Models from ZDF-6 to ZDF-30 can be configured with Hastelloy or enamel linings, tray options, and vacuum system enhancements.
Materials and Structure
Chamber available in Hastelloy or enamel-lined steel, providing excellent resistance to corrosive media. The overall structure supports single-batch processing, ideal for high-value chemical products.
Applications
Ideal for pharmaceutical and fine chemical industries, especially for drying highly corrosive intermediates, APIs, and specialty chemicals.
Customization
We can customize the lining material, tray size, and control system to suit your specific chemical processing requirements.
FAQ
Q: What types of chemicals can this oven handle?
A: It is suitable for highly corrosive chemicals, including strong acids and alkalis.
Q: Is the Hastelloy lining standard?
A: Hastelloy and enamel linings are optional, depending on your processing needs.
Q: Does the oven meet GMP standards?
A: Yes, the design can be made GMP compliant with suitable materials and surface finishes.
Q: Can it be used for solvent drying?
A: Yes, with explosion-proof options available for flammable solvents.
Q: What is the delivery time?
A: Please contact us for lead time based on your configuration.
Inquiry Information
For inquiries, reach out to vincent_zhang@zhanghuayaoji.com or call +86 181-1890-2332.
Image Suggestions
Main Image: corrosion-resistant-vacuum-drying-oven-hastelloy.png – Alt: “Corrosion-resistant vacuum drying oven with Hastelloy chamber”
Detail Image: vacuum-drying-oven-enamel-lining.png – Alt: “Enamel-lined vacuum drying oven for acid-resistant drying”
