Petrochemical Equipment Safety Evaluation Indentation Tester - Bolt Yield Strength Measurement
Model PMT-1000 measures actual bolt yield strength to avoid seal failure from under-preload. With 1000 N max load, 100 Hz data acquisition, and minor-damage indentation (60-120 μm), it ensures accurate material property assessment. Intrinsically safe for hazardous zones, it is perfect for petrochemical, energy, and pharmaceutical industries.
Key Selling Points
- Accurate Yield Strength Measurement: Directly measures actual bolt yield strength, preventing under-preload and seal failures.
- Intrinsic Safety: Complies with hazardous zone regulations, safe for on-site testing.
- Minor-Damage Indentation: Indentation depth of 60-120 μm minimizes impact on bolt integrity.
- High Data Rate: 100 Hz sampling ensures reliable and fast measurements.
- Portable & Flexible: Supports wired/wireless power, easy to use in the field.
Technical Specifications
| Parameter | Value |
|---|
| Maximum load | 1000 N (Max) |
| Actuation range | 25 mm |
| Loading speed | 0.01~30 mm/min |
| Data acquisition rate | 100 Hz |
| Rated voltage of motor | 2.1 V |
| Rated current of motor | 3 A |
| Wired/wireless power | 220 V/24V |
| Testing range | Macro-scale |
| Indentation depth | 60~120 μm |
Models and Options
Standard PMT-1000 comes with necessary fixtures; custom fixtures for various bolt sizes available.
Materials and Structure
Constructed from cemented carbide, stainless steel, and aluminum alloy for durability and corrosion resistance.
Applications
Ideal for petrochemical, energy and power, wind power, aerospace, pharmaceutical, fine chemical, new energy/new materials, and pesticide manufacturing. Ensures bolt integrity in pressure vessels and flanges.
Customization
Customize test procedures and software modules for specific bolt materials and standards.
Case Study
A chemical plant in China has used PMT-1000 for 10 years to test equipment, achieving stable and accurate results quickly.
FAQ
Why measure bolt yield strength?
To ensure correct preload, preventing seal failure and leaks.
What is the maximum load?
Maximum load is 1000 N, suitable for most bolt materials.
How does it ensure safety in hazardous zones?
The tester is intrinsically safe, complying with petrochemical site rules.
What is the indentation depth?
Indentation depth is 60-120 μm, minimal damage.
Can it be used wirelessly?
Yes, supports 24V wireless power for convenience.
What is the data acquisition rate?
It is 100 Hz, providing fast and accurate data.
Inquiry Information
Contact Vincent Zhang at vincent_zhang@zhanghuayaoji.com or +86 181-1890-2332.
