This portable indentation tester PMA-1010 delivers maximum load of 1000 N with an actuation range of 25 mm, enabling nondestructive hardness and material property testing on macro-scale components. It operates at charging speeds from 0.01 to 30 mm/min and data acquisition at 100 Hz, supporting various field testing needs in petrochemical, aerospace, energy, and new energy industries.
Lightweight Design
The instrument weighs less than 10 kg and can be operated with one hand, making it convenient for inspectors to use in tight or elevated positions.
Rechargeable Battery
Integrated rechargeable battery provides over 8 hours of field operation, eliminating the need for external power sources during long testing sessions.
Built-in Self-Check
An internal self-check routine removes the requirement for external calibration blocks, speeding up field setup and ensuring accuracy without additional equipment.
Rapid Data Output
The first data point is available within three minutes of power-on, allowing for swift decisions during inspection workflows.
Technical Specifications
| Parameter | Value |
|---|
| Maximum Load | 1000 N |
| Actuation Range | 25 mm |
| Loading Speed | 0.01~30 mm/min |
| Data Acquisition Rate | 100 Hz |
| Rated Voltage of Motor | 2.1 V |
| Rated Current of Motor | 3 A |
| Wired/Wireless Power | 220 V/24V |
| Testing Range | Macro-scale |
| Indentation Depth | 60~120 μm |
Models and Options
PMA-1010 is the standard portable indentation tester model. Options for magnetic or vacuum suction fixtures are available to secure the device in various orientations.
Materials and Structure
The tester's indenter and frame are constructed from cemented carbide, stainless steel, and aluminum alloy, providing durability and corrosion resistance in industrial environments.
Applications
Designed for the petrochemical industry, energy and power industry, wind power and renewable energy industry, aerospace industry, pharmaceutical industry, fine chemical industry, new energy/new materials industry, and pesticide manufacturing industry. It is suitable for on-site testing of pressure vessels, pipelines, and structural components.
Customization
Custom mounting fixtures and accessory kits can be provided to accommodate specific test points or unusual geometries. Contact our engineering team to discuss your requirements.
Figure 1: Hand-held operation
Figure 2: Tool case for transport
Figure 3: Rechargeable battery operation
FAQ
1. What is the maximum load of the PMA-1010?
The PMA-1010 can apply a maximum load of 1000 N, suitable for macro-scale indentation testing on metallic materials.
2. How long does the battery last?
The rechargeable battery supports over 8 hours of continuous field testing.
3. Can it be used in any orientation?
Yes, the device operates in any orientation, including inverted or tilted, with no directional limitation.
4. Does it require external calibration blocks?
No, the built-in self-check routine eliminates the need for external calibration blocks.
5. What materials can it test?
It is designed for metals, including carbon steel, stainless steel, and aluminum alloys, among other similar materials.
6. What is the data acquisition rate?
The data acquisition rate is 100 Hz, providing fast and accurate readings.
7. How portable is the device?
The instrument weighs less than 10 kg and fits into a standard tool case for easy transport.
