Portable Indentation Tester for Non-destructive Testing of Special Equipment
The PMA-1010 is a portable, non-destructive indentation tester designed for on-site evaluation of mechanical properties of in-service special equipment. With maximum load of 1000 N and indentation depth of 60~120 μm, it provides quick and accurate data without damaging the workpiece.
Key Features
- ✅ Non-destructive testing: Micro indentation ensures no damage to the equipment surface.
- ✅ Portable and easy to operate: Compact design for on-site and field applications.
- ✅ High-precision data: Data acquisition rate of 100 Hz for accurate and reliable results.
- ✅ No sample preparation: Save time and reduce testing costs.
- ✅ Suitable for various materials: Works on cemented carbide, stainless steel, and aluminum alloy.
- ✅ Wide industry applicability: Petrochemical, energy, aerospace, pharmaceutical, and more.
Technical Specifications
| Model | PMA-1010 |
| Maximum Load | 1000 N (Max) |
| Actuation Range | 25 mm |
| Loading Speed | 0.01~30 mm/min |
| Data Acquisition Rate | 100 Hz |
| Motor Ratings | 2.1 V, 3 A |
| Power Supply | 220 V/24 V (Wired/Wireless) |
| Testing Range | Macro-scale |
| Indentation Depth | 60~120 μm |
Models and Options
Standard configuration includes the tester with wired power. Optional wireless power (24 V) version is available for field operations.
Materials and Structure
Engineered to test a variety of materials, including cemented carbide, stainless steel, and aluminum alloy. The device is built with a rugged structure suitable for harsh field conditions, including high temperature, humidity, dust, vibration, and confined spaces.
Applications
Ideal for periodic inspection of pressure vessels, online inspection of pressure piping, in-service equipment life assessment, and weld quality testing. Suitable for petrochemical, energy and power, wind power and renewable energy, aerospace, pharmaceutical, fine chemical, new energy/new materials, and pesticide manufacturing industries.
Customization
Optional wireless power supply, custom fixtures for specific working conditions, and software support for data analysis and reporting.
Case Study
A chemical plant in China used the PMA-1010 to test their equipment. Results were obtained in minutes with high accuracy, enabling quick assessment and continued stable operation for over 10 years.
A special inspection institute has also been using the PMA-1010 for testing special equipment for 10 years, with stable performance and efficient results.
FAQ
1. What is the maximum load capacity of PMA-1010?
The maximum load is 1000 N, suitable for macro-scale indentation testing.
2. Does this tester damage the equipment?
No, it uses micro indentation with depth of 60~120 μm, ensuring non-destructive evaluation.
3. Can it be used in field conditions?
Yes, it is portable, easy to operate, and designed for on-site testing in harsh environments.
4. What materials can it test?
It can test cemented carbide, stainless steel, and aluminum alloy.
5. How fast is the testing?
Results can be obtained in minutes due to high data acquisition rate and loading speed up to 30 mm/min.
6. Is sample preparation needed?
No, the tester requires no sample preparation, saving time and effort.
7. What industries is it suitable for?
It is widely used in petrochemical, energy, aerospace, pharmaceutical, and other industries that need in-service equipment evaluation.
8. Can it be used for long-term monitoring?
Yes, it supports long-term equipment monitoring and provides reliable, repeatable results.
