The PMT-1000 is a portable nondestructive indentation tester designed to rapidly identify material susceptibility to stress corrosion cracking (SCC). It predicts SCC thresholds from indentation curve features, shortening screening cycles significantly. Ideal for oil & gas, chemical, and nuclear sectors where rapid SCC-resistant material screening is critical.
Product Summary
This portable tester performs multi-point rapid screening on a single specimen to locate the most sensitive zones, evaluates SCC sensitivity differences between weld HAZ and base metal, and detects the effect of cold work hardening on SCC susceptibility to optimize forming processes. It eliminates standard tensile specimen preparation, saving material and machining costs.
Key Features
Rapid Screening: Multi-point testing on one specimen to locate sensitive zones (source: image caption).
Non-destructive or Minor-damage: Suitable for thin sheets, small parts, or finished components (source: image caption).
Cost-saving: No standard tensile specimen preparation needed, reducing material and machining costs (source: image caption).
Technical Specifications
Maximum load
1000 N (Max)
Actuation range
25 mm
Loading speed
0.01~30 mm/min
Data acquisition rate
100 Hz
Rated voltage of motor
2.1 V
Rated current of motor
3 A
Wired/wireless power
220 V/24V
Testing range
macro-scale
Indentation depth
60~120μm
Models and Options
This standard model PMT-1000 is available with wired or wireless power options (220V/24V) to suit various field conditions. Custom fixtures can be designed to match specific onsite working conditions, as the company independently develops and matches a variety of supporting fixtures.
Materials and Structure
The tester is designed to evaluate materials including cemented carbide, stainless steel, and aluminum alloy. Its portable structure allows for in-situ testing inside autoclaves and on finished components, making it versatile for different field applications.
Applications
This instrument is suitable for industries such as petrochemical, energy and power, wind power and renewable energy, aerospace, pharmaceutical, fine chemical, new energy/new materials, and pesticide manufacturing. It is used for periodic inspection of pressure vessels, online inspection of pressure piping, in-service equipment life assessment, and weld quality testing.
Case Study
A chemical plant used the PMT-1000 to test equipment, with stable operation over 10 years. The result was described as "Minutes Results in Just, Efficient, Fast, and Highly Accurate."
FAQ
Q1: Can the PMT-1000 be used for in-situ testing inside autoclaves?
Yes, the PMT-1000 performs in-situ testing inside autoclaves, as highlighted in product images.
Q2: What is the maximum load capacity?
The maximum load is 1000 N.
Q3: Can it be used on thin sheets or finished components?
Yes, it performs non-destructive or minor-damage screening on thin sheets, small parts, or finished components.
Q4: Does it require standard tensile specimen preparation?
No, it eliminates standard tensile specimen preparation, saving material and machining costs.
Q5: What industries is it suitable for?
It is suitable for petrochemical, energy, aerospace, pharmaceutical, and other industries listed in the applicable industries.
Q6: How does it help in evaluating weld HAZ and base metal?
It evaluates SCC sensitivity differences between weld HAZ and base metal, as shown in product images.
