Residual Stress Indentation Tester for In-Service Pipeline Re-Testing and Relaxation Verification

Name: "Residual Stress Indentation Tester for In-Service Pipeline Re-Testing and Relaxation Verification"
Rating: 5 (642 reviews)

SKU: 6016231177

Model: PMA-1010

Product Details

Residual Stress Indentation Tester – PMA-1010 for Pipeline Re-Testing

URL Slug: residual-stress-tester-pipeline-retesting

Product Summary

Model PMA-1010 is a portable nondestructive indentation tester specifically suited for in-service pipeline re-testing. It allows定点 (point-specific) measurement to verify stress relaxation over time. Its rapid testing capability completes inspections at dozens of points within a short turnaround outage, minimizing downtime.

Key Features

Point-Specific Re-Testing: Allows re-testing at exact locations for accurate relaxation tracking.
High Throughput: Dozens of test points in a short turnaround outage.
Intrinsically Safe: Usable in explosive environments.
Portable & Lightweight: Easy to transport along pipelines.
Wireless Power Option: 24V operation for remote locations.

Technical Specifications
Parameter	Value
Maximum Load	1000 N
Actuation Range	25 mm
Loading Speed	0.01–30 mm/min
Data Acquisition Rate	100 Hz
Motor Ratings	2.1 V, 3 A
Power Source	220 V (wired) / 24 V (wireless)
Testing Range	Macro-scale
Indentation Depth	60–120 μm

Models and Options

PMA-1010 standard model; special mounting brackets for different pipe diameters are available.

Materials and Structure

Indenter made of cemented carbide; housing of stainless steel; frame of aluminum alloy.

Applications

Specifically for petrochemical pipelines, in-service inspection, and stress relaxation monitoring. Also applicable in power plants and oil & gas facilities.

Customization

Custom clamps for various pipe sizes and surface conditions can be provided.

Case Study

Chemical Plant (China): Utilized for equipment testing, achieving stable operation for 10 years. Highlight: Minutes Results in Just, Efficient, Fast, and Highly Accurate.

FAQ

Q: How does re-testing improve safety?
A: By verifying stress relaxation, it ensures that residual stresses remain within safe limits.

Q: Can it be used on live pipelines?
A: Yes, it is designed for in-service testing without disrupting operations.

Q: What is the minimal distance between test points?
A: The indenter spacing depends on material; typically about 1 mm to avoid interference.

Q: How long does a single test take?
A: Due to high loading speed up to 30 mm/min, each test can be completed in seconds.

Q: Is data analysis software included?
A: Yes, the system includes data processing and analysis software.

Inquiry Information

Contact Vincent Zhang via email vincent_zhang@zhanghuayaoji.com or WhatsApp +1(805)869-8509.

Image Suggestions

PMA-1010 enabling pipeline re-testing for stress relaxation
