Residual Stress Indentation Tester for Storage Tank Bottom Plate Weld Measurement

Name: "Residual Stress Indentation Tester for Storage Tank Bottom Plate Weld Measurement"
Rating: 5 (514 reviews)

SKU: 9570256079

Model: PMA-1010

Product Details

Residual Stress Indentation Tester – PMA-1010 for Storage Tank Weld Inspection

URL Slug: residual-stress-tester-storage-tank-weld

Product Summary

Model PMA-1010 is a portable nondestructive indentation tester designed to measure welding residual stress in large storage tank bottom plates. It offers dual-parameter (hardness and residual stress) on-site testing, aiding in weld quality control and preventing failure.

Key Features

Weld Stress Measurement: Specifically designed for tank bottom plate welds.
Dual-Parameter Testing: Simultaneously measures hardness and residual stress.
High Load Capacity: 1000 N maximum load for robust testing.
Fast Data Acquisition: 100 Hz rate for detailed weld stress profiles.
Portable Design: Easy to move around large tanks.

Technical Specifications
Parameter	Value
Maximum Load	1000 N
Actuation Range	25 mm
Loading Speed	0.01–30 mm/min
Data Acquisition Rate	100 Hz
Motor Ratings	2.1 V, 3 A
Power Source	220 V (wired) / 24 V (wireless)
Testing Range	Macro-scale
Indentation Depth	60–120 μm

Models and Options

PMA-1010 standard; optional magnetic bases for tank surfaces.

Materials and Structure

Cemented carbide indenter, stainless steel body, aluminum alloy frame.

Applications

Petrochemical storage tanks, pressure vessels, and structural steel fabrication where weld residual stress assessment is critical.

Customization

Special anvils for curved surfaces and confined spaces are available.

Case Study

Special Inspection Institute (China): Tested special equipment successfully with stable operation for 10 years.

FAQ

Q: Why measure weld residual stress?
A: High residual stresses can lead to cracking and failure; measuring helps ensure weld integrity.

Q: Can it be used on tank bottom plates?
A: Yes, it is designed for such applications.

Q: What is the indentation depth?
A: Between 60 and 120 μm, minimizing surface damage.

Q: Does it provide both hardness and stress?
A: Yes, dual-parameter testing is a key feature.

Q: Is it wireless?
A: It offers both wired (220V) and wireless (24V) power options.

Inquiry Information

For more details, contact Vincent Zhang: vincent_zhang@zhanghuayaoji.com or WhatsApp +1(805)869-8509.

Image Suggestions

PMA-1010 measuring welding residual stress in storage tank bottom plate
